Rheem Furnace Parts 47-25349-05 Temperature Control Limit Switch

Temperature Control Limit Switch, a key Rheem furnace part, protects your gas furnace by automatically resetting at safe operating temperatures. This board-mount, auto-reset limit switch is designed for reliable overheat protection in standard residential systems and is compatible with 120/230V AC power supplies.

With a temperature range of 200°F open and 180°F closed, it ensures early shutoff to prevent damage. It features SPST, NC contact configuration, 1/4 inch quick-connect terminals, and an enclosed disc face for durability. The unit installs on the furnace board with a 3 inch insertion depth and fits a mounting board size of 1-5/8" x 1-7/16". Color code orange helps identify it in service.

• Type: Board-mount, auto-reset limit switch for gas furnaces
• Electrical: 120/230V AC, 15/10 Amp
• Contacts: SPST, NC
• Terminals: 1/4" quick-connect
• Physical: Enclosed disc-face, 3" insertion depth, mounting board 1-5/8" x 1-7/16"
• Color: Orange
