Rheem Furnace Parts 47-25350-01 Temperature Control Limit Switch

Temperature Control Limit Switch for Rheem furnaces delivers reliable overheat protection with fast auto reset. Model 47-25350-01 is a board-mount limit switch crafted for gas furnaces, featuring a 60-degree strap angle for flexible mounting.

Designed for safety, it opens at 190°F and closes at 170°F, with +/-5 open tolerance and +/-7 close tolerance. It is rated for 120/230V AC and 15/10A, with SPST NC contact configuration for straightforward wiring. The 1/4 inch quick-connect terminals simplify installation, while the 3-inch insertion depth and board size of 1-3/4 x 1-9/16 inch fit standard control boards. Color Code: Red.

• Type: Board Mount, 60° strap angle, Auto Reset
• Temperature: Open 190°F / Close 170°F with tolerance ±5 (Open) and ±7 (Close)
• Electrical: 120/230V AC, 15/10A, SPST, NC
• Connections: 1/4" quick-connect terminals
• Mounting: Insertion depth 3", board size 1-3/4" x 1-9/16"
• Application: Gas furnace limit switch replacement part
