Rheem Furnace Parts 47-25350-07 Temperature Control Limit Switch

The Temperature Control Limit Switch is a critical safety component for Rheem furnace systems, model 47-25350-07.

Designed for board-mount installation with auto reset and a 60° strap angle, this switch guards your gas furnace by cycling operation between 180°F (open) and 160°F (close).

With a 120/230 VAC rating and 15/10 A, it delivers reliable protection in standard Rheem furnace configurations. The SPST, NC contact configuration ensures simple, fail-safe shutoff, while 1/4" quick-connect terminals enable quick, secure wiring. The enclosed disc-face design adds durability against dust and debris, and the green color code helps with fast identification during maintenance.

• Type: Board Mount, 60° Strap Angle, Auto Reset
• Temperature Range: Open 180°F, Close 160°F
• Electrical: 120/230 VAC, 15/10 A
• Contacts: SPST, NC
• Connection: 1/4" Quick Connect
• Application: Gas Furnace
• Mounting: Insertion Depth 3", Board Size 1-3/4" x 1-9/16"
• Durability: Disc Face Enclosed
• Color Code: Green
