Rheem Furnace Parts 47-25350-09 Temperature Control Limit Switch

Temperature Control Limit Switch ensures safe operation in Rheem furnace systems with automatic reset after an overheat event. The 47-25350-09 part is a gas furnace limit switch designed for board-mount installations, delivering reliable protection and long-lasting durability.

Designed for reliable operation in residential and light commercial gas furnaces, this temperature control limit switch withstands HVAC conditions with an enclosed disc-face for durability. Its board-mount design simplifies replacement on compatible Rheem furnace parts, helping minimize downtime and maintain safe shutoffs when temperatures rise.

Ideal for Rheem furnace parts and other gas furnace limit switch applications, this unit combines precise temperature control with a compact, enclosed disc-face design. It supports quick wiring via 1/4" quick-connect terminals and fits with a 3" insertion depth on standard mounting boards.

• Type: Board Mount, 60° strap angle, Auto Reset
• Temperature range: Open 200°F / Close 180°F
• Electrical: 120/230 VAC, 15/10 A
• Contacts: SPST, NC
• Connection: 1/4" Quick Connect
• Application: Gas Furnace
• Physical: Enclosed disc-face, insertion depth 3", board size 1-3/4" x 1-9/16"
• Tolerances: Open ±5°F, Close ±7°F
