Rheem Furnace Parts 51-23055-12 Condenser Motor

Condenser Motor for Rheem furnace applications delivers reliable performance and simple replacement. The 51-23055-12 model is a compact, direct-drive motor designed for condenser use, delivering 1/5 HP, 208–230 V AC at 60 Hz, with a single 825 RPM speed and 1-phase operation.

It features a NEMA 48 frame, sleeve bearing design, and a 5 μF capacitor with 370 V rating to ensure smooth starting and steady operation. This condenser motor is a dependable replacement among Rheem furnace parts and is built to withstand demanding HVAC environments.

Engineered for condenser applications, this motor uses a direct-drive system and is compatible with standard Rheem furnace parts. The compact body measures 5-5/8 in diameter by 4-3/8 in length, with an overall length of 8-1/8 in and a 1/2 in shaft diameter by 3-3/4 in length. The reversible design adds installation flexibility and supports various mounting configurations.

• Power: 1/5 HP
• Voltage: 208–230V AC, 1-Phase, 60 Hz
• Current: FLA 1.3 A at 230 V
• Speed: 825 RPM, 1-speed, reversible
• Frame/Mounting: NEMA 48; Shell-Band/Shell-Screw/Thru-Bolt
• Bearings/Drive: Sleeve bearing; Direct drive
• Capacitance: 5 μF at 370 V
• Dimensions: Overall length 8-1/8 in; body 5-5/8 in Ø × 4-3/8 in; shaft 1/2 in Ø × 3-3/4 in
